Illuminate USB-C Light Bar with 4K Autofocus Webcam

Roll over image to zoom in Click on image to zoom

Illuminate USB-C Light Bar with 4K Autofocus Webcam

Name: Illuminate USB-C Light Bar with 4K Autofocus Webcam
Brand: ALOGIC Japan
SKU: ALCMILSGR
Price: 22499.0 JPY
Availability: InStock
Rating: 4.71 (7 reviews)

SKU: ALCMILSGR

Color: Space Grey

Variant

Price:

¥22,499

Stock:

In Stock

Quantity:

User Manual

Specification Sheet

SEE AND BE SEEN

Light Up Your World

Fully adjustable, Illuminate puts you in control of your workspace with warm or neutral lighting that doesn’t add any unwanted glare to your computer screen.

Controls at your Fingertips

Adjust with a Touch

Intuitive touch controls make it quick and easy to adjust Illuminate's brightness and colour temperature.

Dial into Perfection

Swipe to adjust the light with Illuminate's snap-on magnetic remote control dial.

Your 4K Glow Up

If you're still using your laptop's low-angle, unflattering webcam for video calls, you owe it to yourself to try something better. Fully compatible with Mac and Windows, Illuminate's wide-angle 12MP (4K) autofocusing webcam is perfect for meetings, streaming and video recording.

Snap-On Privacy

When your call is over, just snap-on Illuminate's magnetic privacy cover over the webcam for peace of mind. Additionally, Illuminate's bright status LED makes it easy to tell when you're sharing.

Easy to Setup and Adjust

Tilt with a Touch

Illuminate's flexible mount allows for tilting to angle the camera or light.

Mounts in a Second

Just unfold the mount, place it on your monitor, and push to secure.

Anti-Slip Rubber

Ensures that Illuminate stays in place, without scratching your monitor.

Designed for Edge

While Illuminate light bars work with any monitors 8-30mm thick, they’re colour matched to our Edge Ultrawide Monitors, providing a perfectly angled 4K webcam powered via Edge’s USB-C ports.

Connects with One Cable

Simply connect Illuminate to your computer or monitor's USB-C port and it's good to go.

Frequently Asked Questions

General

What resolution is Illuminate’s camera?

Illuminate has a 12MP webcam sensor, which roughly corresponds to a 4K resolution (4000x3000).

It outputs the following resolutions and framerates at 16:9 aspect ratio: 4k 30 FPS, 1080p 60 FPS, 1080p 30 FPS, 720p 60 FPS

What colour temperatures can I set Illuminate’s Light Bar to?

Illuminate’s light bar can be adjusted between a warm 2,800K and a more neutral 6,500K.

Using the remote control, you can dial into your preferred temperature between these values, while by tapping the Colour Temperature button on the lightbar itself, you can quickly switch between three presets: 1. 2,800K (Warm) 2. 4,500K (Balanced) 3. 6,500K (Neutral)

Illuminate is ‘Designed for Edge’. Does it still work with other monitors?

Absolutely.

Illuminate can be used with any monitor that is between 8-30mm thick at the top and has an available USB-A or USB-C port that can supply 5V (5V/1A) of power and supports USB 2.0 (or newer) data transfer.

Can I use Illuminate with USB-A ports, or just USB-C?

Illuminate can be used with either a USB-A or USB-C port, as long as it supports 5V (5V/1A) of power and USB 2.0 (or newer) data transfer.

We recommend consulting the product’s user manual, or the manufacturer’s website to make sure your port supports Illuminate before purchase.

Illuminate does not include a USB-C to USB-A cable, but is compatible with USB-C to USB-A adapters (such as the Ultra USB-A to USB-C Mini Adapter ) or any USB-C to USB-A cables.

Does the webcam with work Microsoft Teams/Slack/Zoom?

Illuminate’s webcam is compatible with all programs that work with standard laptop or USB-C webcams, including all popular video conference platforms.

Troubleshooting

My webcam looks blurry, with a blue tint!

If Illuminate’s webcam looks blurry, or seems to have a blue tint to it, you may not have removed the protective film. Check your webcam – there should be a little tab you can pull off. If there isn’t a tab, look closely at the camera and try rubbing one of the sides to see if there’s still a plastic film – sometimes the pull tab can get stuck inside the camera itself.

If you’re sure there’s no film and your camera remains either blurry or blue-tinted, please get in touch with our support team: support.jp@alogic.co

My light bar is turning off at maximum brightness!

If Illuminate is turning off when it hits max brightness, this indicates Illuminate is not receiving enough power. Ensure the port can supply at least 5W of power – not all laptop or computer monitor ports support this. We recommend consulting the product’s user manual, or the manufacturer’s website.

My webcam isn’t working!

If Illuminate’s webcam “Alogic Illuminate Webcam” does not appear in the list of connected cameras, ensure the USB port you’ve connected Illuminate to supports USB 2 data. We recommend consulting the product’s user manual, or the manufacturer’s website to double check the ports support USB 2.0 data transfer.

Specifications

Part No.: ALCMILSGR / ALCMILSLV

Physical Characteristics

Light Bar: Product Dimensions: 480mm (L) x 93mm (D) x 47.5mm (H)
Weight: 327g
Materials: ABS / Aluminium
Connectivity: Connects via USB-C (USB 2.0)
Control: Touch sensitive buttons for On/Off, Dimming and Colour Temperature
Privacy: Detachable Magnetic Privacy Cover
Remote Control: Product Dimensions: 76mm (L) x 76mm (D) x 34mm (H)
Weight: 110g
Materials: ABS / Aluminium
Connectivity: Connects via USB-C for charging
Control: Touch sensitive buttons for On/Off, Dimming and Colour Temperature
Battery: Includes built-in 1000mAh rechargeable battery
LED Light Bar Specs: Brightness: 0-100% adjustable
Colour Temperature: 2800k-6500k adjustable
Webcam Specs: Sensor size: 12MP 4:3 (4000x3000)
Supported resolutions: 4k 30 FPS 16:9, 1080p 60 FPS 16:9, 1080p 30 FPS 16:9, 720p 60 FPS 16:9
Field of View: 80°
Focus range: 20cm - 3m
Flicker reduction: 50 Hz / 60 Hz
Focus: Autofocus
Microphone: Built-in

Device Compatibility

Operating Systems: Windows®, macOS™, Android, Linux
Software: USB video streaming compatible with Teams, Zoom, Skype, Line and more
Package Includes: Light Bar with 4k Autofocus Camera, Wireless Remote Control, USB-C to USB-C Cable & User Manual
Warranty: 2 Years
Barcode (EAN): ALCMILSGR - 9350784102386 | ALCMILSLV - 9350784102393

Downloads

User Manual

Specification Sheet

The light bar with webcam has been good when I work from home. I like the adjustability of the lamp.

I noticed the rubber grip attached to the base has started to lift alot, although I haven’t owned this product for long. I suggest improving this part.

Love the variable light options and integration with an excellent inbuilt camera/mic

Arrived fast and works great!

Tbh I don’t know why I didn’t get this sooner. It’s was super easy to put up, plug in and start using!
Highly recommended!!

WebCam LED mit top Qualität

WebCam LED mit top Qualität und tollen Funktionen. So wünscht man sich Angehörige der apple Familie. alles gut, Andi Berlin

Great product - just a couple of quirks

Overall this is a great product that is just as you see it in the promotional photos. Only downsides are it's not intuitive for first time users how to use the touch controls and no clear instructions were provided. Also personal opinion but company logo is not on par with product so having it very visible on product kind of detracts from what is a quality item. Webcam is good compared to others I've tried. Overall definitely recommend.

Elegant, functional solution

Had the previous camera which was rather clunky and microphone not the best. This is a serious upgrade and the light works well. Only gripe - the instructions are in such a small, faint font on flimsy stock that it took me longer than it should have done to figure out how to use the light controller.
